The F501 is the smaller of the two floorstanding loudspeakers in the F500 series but capable of delivering low bass and effortless dynamics from a compact, small footprint cabinet. Bringing additional scale and power to the F500 series’ signature clarity and articulation, the 150mm (6″) proprietary IsoFlareTM driver is accompanied by a matched 150mm (6″) bass driver. The IsoFlareTM driver delivers isotropic energy radiation with point source constant directivity providing outstanding stereo imaging, even off axis. Ideal for small to medium-sized rooms, the F501 is supplied with a dedicated plinth incorporating our TRX360TM Tractrix diffuser system, which integrates bass energy uniformly into the room

The luxuriously finished, contemporary styled cabinet is available in a choice of dark oak or black oak real wood veneer. Enhancing its aesthetic appeal, it has a gently curved front and rear baffle which additionally benefits the acoustic performance by reducing colouration effects.

Clear

SKU 11111111 Category Tag


Share
Physical
System Type 2 ½ way, downwards firing port, with TRX360TMTractrix diffuser. Twin cavity coupled reflex
Recommended amplifier power (Watt RMS) 35- 150
Continuous power handling (Watt RMS) 75
Sensitivity (2.83 Volt @ 1m) 90dB
Nominal impedance 8 Ohm
Frequency response (-6dB typical in room) 36Hz- 34kHz
Drive unit complement 1 x 150mm IsoFlareTM, multi-fibre bass/ mid with 25mm titanium ome compression tweeter 1 x 150mm multi-paper bass
Crossover frequency 250Hz & 1.7kHz
Crossover type 2nd order low pass, 1st order high pass
Dimensions - HxWxD 984 x 200 x 320 mm (38.8 x 7.9 x 12.6”)
Weight - Each 18.9 kg (41.7 lb)
Finishes Dark Oak / Black Oak
